Honsberg - UR1-040GM
| Manufacturer | Honsberg |
|---|---|
| Part Number | UR1-040GM |
| Inner Code | 3301274 |
| Description | flow monitor |
| Custom Code | 85365080 |
| Technical specification | Article 942052 Nominal width: DN 40 Connection type: female thread G 1½ T-piece: nickel-plated brass Body: nickel-plated brass Compressive strength: PN 25 Seal: NBR Media temperature: -20... +110 °C Ambient temperature: -20... +70 °C adjustment range H2O: 30... 38 l/min H2O Contact tube: brass Adjustment: clamping plate m. 2 hexagon socket screw el. Connection: cable 1.5 m el. Contact material: reed switch Contact rating: 230 V AC 1 A 50 VA Connection pattern: normally open/normally closed, connection pattern no. 0.225 Degree of protection: IP65 Flow direction: Horizontal from left |
| Weight | 0.55 |
Please contact us to request a price quote for Honsberg - UR1-040GM, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
