Honsberg - UR1-020GM-956510
| Manufacturer | Honsberg |
|---|---|
| Part Number | UR1-020GM-956510 |
| Inner Code | 4959797 |
| Description | Flow Switch |
| Custom Code | 90261029 |
| Technical specification | Article: UR1-020GM-956510 Article number: 956510 Description: Flow Switch Nominal diameter: DN 20 Connection type: Female thread G ¾ T-piece: Brass nickel-plated Body: Brass nickel-plated Pressure resistance: PN 25 Seal: NBR Media temperature: -20 ... +110 °C Environmental temperature: -20 ... +70 °C Adjustment H?O: 5 l/min H2O Contact tube: Brass Adjustment: Clamping plate with 2 Allen screws Electrical connection: Cable 3 m Max. contact load: 230 V AC 1 A 50 VA Connection diagram: Normally-open contact, connection diagram no. 0.212 Protection type: IP65 Flow direction: Horizontal from the left |
Please contact us to request a price quote for Honsberg - UR1-020GM-956510, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
