Honsberg - UR1-015GM
| Manufacturer | Honsberg |
|---|---|
| Part Number | UR1-015GM |
| Inner Code | 3849961 |
| Description | Flow switch |
| Custom Code | 85365080 |
| Technical specification | 941543 (order code: UR1-015GM) flow monitor Nominal size: DN 15 Connection type: internal thread G ½ T-piece: nickel-plated brass Body: nickel-plated brass Pressure resistance: PN 25 Seal: NBR Media temperature: -20... +110 °C Ambient temperature: -20... +70 °C H2O adjustment range: 4... 4.5 l/min H2O Contact tube: brass Adjustment: clamping plate with 2 inner hexagonal screws El. Connection: 1.5 m cable El. Contact material: reed switch Contact capacity: 230 V AC 1 A 50 VA Connection diagram: closer/ opener, connection diagram No. 0.225 Protection class: IP65 Flow direction: Horizontal from left |
Please contact us to request a price quote for Honsberg - UR1-015GM, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
