Honsberg - MR1K-020GM004-104 (945665)
| Manufacturer | Honsberg |
|---|---|
| Part Number | MR1K-020GM004-104 (945665) |
| Inner Code | 3761888 |
| Description | Flow Switch |
| Custom Code | 85365080 |
| Technical specification | MR1K flow monitor Display options: Without mechanical display Nominal size: DN 20 - G ¾ Connection type: internal thread Connection material: nickel-plated brass Pressure resistance: PN 200 Internal parts: stainless steel Seals: NBR Media temperature: -20... +120 °C Ambient temperature: -20... +70 °C H2O switching range: 0.4... 4 l/min H2O Switch head: plastic, flat Adjustment: long hole El. Connection: For M12x1 circular connectors, 4-pin El. Contact: reed switch Contact rating: 24 V DC 1.5 A 50 W Wiring diagram: Closer, yellow diode, connection diagram No. 0.388 Protection class: IP65 Flow direction: Horizontal from left Signal lamp: yellow in the switch head Design: Desina |
| Weight | 1.1 |
Please contact us to request a price quote for Honsberg - MR1K-020GM004-104 (945665), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
