Honsberg - HD1K-020GK040-708
| Manufacturer | Honsberg |
|---|---|
| Part Number | HD1K-020GK040-708 |
| Inner Code | 4845129 |
| Description | flow monitor |
| Custom Code | 85365080 |
| Technical specification | Version: standard Display option: Without mechanical display Nominal size: DN 20 - G ¾ Connection type: internal thread Connection material: stainless steel Seal: FKM Pressure resistance: PN 200 Media temperature: -20... +120 °C Ambient temperature: -20... +70 °C H2O switching range: 4... 40 l/min H2O Switch head: metal/ plastic sliding plate Adjustment: sprocket, min.-max. scale El. Connection: DIN 43650-A/ISO 4400 plug El. Contact: reed switch Contact capacity: 120 V AC 0.18 A 5 VA/175 V DC 0.25 A 5 W Connection diagram: Changer, connection diagram No. 0.213 Protection class: IP65 Flow direction: Horizontal from left |
Please contact us to request a price quote for Honsberg - HD1K-020GK040-708, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
