Honsberg - FX-015AP
| Manufacturer | Honsberg |
|---|---|
| Part Number | FX-015AP |
| Inner Code | 284245 |
| Description | Flow Switch |
| Custom Code | 85365080 |
| Technical specification | 942876 Spring-supported: Without spring support Nominal diameter: DN 15 Connection: external thread G ½ A Housing: POM Compressive strength: PN 10 Seal: NBR Media temperature: -20 ... +70 °C (80 °C at 6 bar) Ambient temperature: -20 ... +70 °C Range for fixed switching point: 0.4 ... 5 l/min H2O Switching point H2O: 0.4 l/minH2O off, approx. 0.7 l/min on Flow direction: Vertical from below Switch head: plastic El. Connection: cable 0.5 m El. Contact: Reed switch Contact rating: 230 V AC 1 A 50 VA Connection diagram: NO contact, connection diagram no. 0.372 Protection class: IP65 |
| Weight | 0.5 |
Please contact us to request a price quote for Honsberg - FX-015AP, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
