Honsberg - P/N: 942530, Type: FF-040GR015S-942530
| Manufacturer | Honsberg |
|---|---|
| Part Number | P/N: 942530, Type: FF-040GR015S-942530 |
| Inner Code | 277528 |
| Description | Flow monitor |
| Custom Code | 85365080 |
| Technical specification | Nominal size: DN 40 Connection: internal thread G 1½ Case: nickel-plated gunmetal Pressure resistance: PN 16 Internal parts: POM Seal: NBR Media temperature: -20... +90 °C Ambient temperature: -20... +70 °C Adjustment range: SC measuring flask Switching point: 1.5 l/min H2O down, 1.7 l/min rising Switch head: nickel-plated brass El. Connection: PG with 1.8 m cable El. Contact: reed switch Contact rating: 230 V AC 1 A 50 VA Connection diagram: Closer, connection diagram No. 0.212 Protection class: IP65 Flow direction: Horizontal from the left System Cleaners 942530 |
| Weight | 4.056 |
Please contact us to request a price quote for Honsberg - P/N: 942530, Type: FF-040GR015S-942530, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
