Hoffmann - 302896 32AD
| Manufacturer | Hoffmann |
|---|---|
| Part Number | 302896 32AD |
| Inner Code | 4823312 |
| Description | Precision ER collet chuck HDC |
| Technical specification | for ER collets 32AD Clamping ⌀ D1 2-20 mm Adapter BT 40 A = 90 Arbor standard JIS B6339; JIS B6339 Shape AD Balance quality G at rotational speed G 2.5 at 25,000 rpm Concentricity ER collet with CP collet chuck ≤ 6 µm Concentricity HP collet with CP collet chuck ≤ 3 µm Concentricity ER collet with HDC collet chuck ≤ 6 µm Concentricity HP collet with HDC collet chuck ≤ 3 µm Machining strategy HSC Clamping range 2 mm - 20 mm Overhang dimension A 90 mm External ⌀ D 53 mm |
Please contact us to request a price quote for Hoffmann - 302896 32AD, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
