HIMMEL - TM165.1 x 400 0,37 0,39
| Manufacturer | HIMMEL |
|---|---|
| Part Number | TM165.1 x 400 0,37 0,39 |
| Inner Code | 4232636 |
| Description | drum motor |
| Technical specification | 5670001185 Trommeltype / Type: TM165.1x400 Trommeldurchmesser / Drum diameter: Ø 164 / 165 Länge / lenght [mm]: 400 Trommelform / Drumshell design: ballig / crowned Nennleistung / Nominalpower [kW]: 0.37 Nennleistung / Nominal power [HP]: 0.5 Nenngeschwindigkeit / Nominal speed [m/s]: 0.39 Nennspannung / Nominalvoltage [V]: 220-240/380-420 Nennfrequenz / Nominal frequency [Hz]: 50 Phasenanzahl: 3~ Betriebsart / Duty type: S1 Elektrische Ausführung / Elektrical design: CE Isolationsklasse / Insulation class: F Wicklungsschutz / Motor protector: WT 120°C Schutzart / protection class: IP66 Verbindung [Deckel/Mantel]: geklebt/glued Anschlußart / Electrical connection: Klemmenkasten aus Aluminium (Typ 07) / terminal box from aluminium (type 07) Kabelabgang / cable outlet: unten-links/bottom-left Schlüsselflächen-Lage / Direction of spanner: senkrecht / vertical Wellenmaße / Shaft dimensions d / e / f / b [mm]: 40/30/45/20 Einspannlänge EL / Dimension EL [mm]: 440 Material Trommel / Drumshell material: Stahl / mild steel Material Wellen / Shaft material: Stahl / mild steel Material Deckel / Caps material: Aluminium / aluminium Material Spaltdichtung / Gap ring material: Stahl, verzinkt / galvanised steel Abdichtung / Sealing: Nilosring LST-O Ölart / Oil type: CLP 100 Miner.oil Schaltbild / Wiring diagramm: A170812-3 |
Please contact us to request a price quote for HIMMEL - TM165.1 x 400 0,37 0,39, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
