HIMMEL - KG75.01-XL/2 M27 Re
| Manufacturer | HIMMEL |
|---|---|
| Part Number | KG75.01-XL/2 M27 Re |
| Inner Code | 3698759 |
| Description | flat engine |
| Technical specification | Flachmotor KG75.01-XL/2 M27 Re 374730 - CSA - Ausführung Art.nr.2140001606 Maßblatt: 1NJ100000000006 K-Modellreihe / design series: KG75.01 Typ / type: K75-XL/2 K-Maßblatt / dimension sheet: 1NJ100000000006 Farbe / colour: RAL 7035 Lichtgrau 2K / Light grey 2K-PUR Bauform / mounting position: B3 Schutzart / protection class: IP54 K-Leistungsschild / name plate: Klebeschild 29x53 W.Durchmesser / shaft diameter: 30,0 mm W.Länge / shaft-length: 116,0 mm (mitte Fußbohrung bis Anfang Werkzeug) Wellengewinde / shaft thread: M27 rechts K-Flanschscheiben Ø / external diameter flange: 140 mm K-Werkzeugbreite / tool width: max. 5 mm KK-Ausführung / Terminal box type: Aluminium-M20x1.5 / aluminium-M20x1.5 KK-Lage / Terminal box position: 1B Elektrische Ausführung / Elektrical design: CSA-Ausführung - jedoch nicht stempeln Leistung / Power [kW]: 22.0 HP Motordrehzahl / Motor speed [1/min; 1/rpm]: 3520 Frequenz / Frequency [Hz]: 60 Spannung / Voltage [V]: 460 Strom / Current [A]: 26.00 Schaltung / Wiring: S102 (D) Betriebsart / Duty type: S6-60% Wicklungsschutz / Motor protector: 3WT`s 155°C Isolationsklasse / Insulation class: F Schaltbild Motor / Connection diagram motor: A2059 + A010414 |
| Weight | 90 |
Please contact us to request a price quote for HIMMEL - KG75.01-XL/2 M27 Re, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
