Herzog - HBF 4000 (Package 1 )
| Manufacturer | Herzog |
|---|---|
| Part Number | HBF 4000 (Package 1 ) |
| Inner Code | 3332359 |
| Description | SURFACE GRINDING MACHINE |
| Technical specification | Automatic sample preparation machine with coarse grinding device, fine grinding device and milling device. This machine is suitable for the preparation of steel and iron samples for optical emission and X-ray fluorescent analysis. 1 Coarse grinding belt: length 2000 mm, width 200 mm (recommend grit 40, 60) Incl. 1 Fine grinding belt : length 2000 mm, width 200 mm (recommend grit 80, 100) Incl. -------------------------------------------------- Included: 1 Coarse grinding belt: length 2000 mm, width 200 mm (recommend grit 40, 60) 1 Fine grinding belt : length 2000 mm, width 200 mm (recommend grit 80, 100) 1 Grain 40 - 200 mm width 1 Grain 60 - 200 mm width 1 Grain 80 - 200 mm width 1 Grain 100 - 200 mm width 1 Grain 120 - 200 mm width Cutter head for steel samples - One cutter head is included in the machine 1 Cutter tip made of tungsten carbide -Package 1 HBF 4000 1 Recommended set of spare parts for HBF 4000 - for a period of about 2 years and 3 shift operation. Wooden cases HBF 4000 and control cabinet for overland and sea transport 1 Dust extraction unit C10-3 K5 -With control cabinet for automatic operation 1 Dust collecting tube (incl. 1 meter) 1 Non-return valve 1 Spark trap 1 Recommended set of spare parts for C10-3 K5 1 PACKING Wooden case for dust extraction unit For overland and sea transport (packing material special treated and marked according to IPPC/ISPM15) --------------------------------------------------------------- Technical description: Model HBF 4000 ,Colour RAL 5007 / 7035 ,Lettering English.Instruction manual 1 English manual Accessories 1 set of grinding belts consist of 2 grinding belts grit 40 2 grinding belts grit 60 2 grinding belts grit 80 2 grinding belts grit 100 2 grinding belts grit 120 1 set of cutting tips 1 set of spanners Weights and Dimensions Dimension Machine (LxWxH) 1665 x 840 x 1620 mm Weight Machine Approx. 1400 Kg Dimension Electric cabinet (LxWxH) 1200 x 400 x 2000 mm Weight Electric cabinet Approx. 500 kg Grinding belt dimensions Coarse grinding belt (recommend) 200 x 2000 mm grain 40,60 Fine grinding belt (recommend) 200 x 2000 mm grain 80,100 Cutter head dimensions Cutter head Diameter 100mm Cutting tips 4 pieces WCE 10 Power supply and consumption Voltage 400 V, 50 Hz, 3-phase Neutral conductor Not required Power consumption Approx. 20 kVA Cable connection at the machine Location On the left-hand side of the machine Compressed air supply and consumption Pressure Min. 5 bar, max. 10 bar Consumption Approx. 750 dm3N per sample Connection sleeve Nominal diameter 19 mm Location On the left-hand side of the machine Water supply and consumption Pressure Min. 3 bar, max. 10 bar Consumption Approx. 1.5 l per sample Connection sleeve Nominal diameter 19 mm Location On the left-hand side of the machine Discharge / water Diameter of the discharge sleeve 40 mm outside diameter Discharge water pressure Zero Location On the left-hand side of the machine Discharge/dust extraction Diameter of the dust extraction sleeve Outside diameter 120 mm/inside diameter 115 mm Required exhaust rate 15 m3/min. at 2100 Pa Location of the dust extraction sleeve On the right-hand side of the machine Sample clamping device Type 2 parallel clamping jaws, self-centring Clamping region diameter Max. 60 mm Clamping region width 7-60 mm Processed samples Material Steel and iron Form Without butt, round, oval or square samples with two parallel clamping faces, and double thickness samples. Sample hardness for milling programs Max. 40 HRC Sample hardness for grinding programs Max. 64 HRC Temperature Max. 800°C Processing parameters Grinding depth Max. 2 mm programmable in steps of 0,05 mm ** Processing cycle duration depending upon the program *** Number of processing programs Numbers 16 Sample cooling Cooling type By means of cooling nozzles Cooling medium Compressed air and water Sample insertion and discharge Insertion method Manual in the sample insertion mask Discharge method Sample prepared for manual retrieval Electrical switch cabinet Programmable Controller SIMATIC S7 Control voltage 24 V DC Ingress protection IP 44 Insulation class B The design of the machine complies with the applicable accident prevention and VDE regulations. Technical description: Model UNICELL C 10-3 K5 Colour RAL 7035 Dimensions & Weight Machine 928 x 1380 x 2803 mm Weight 563 Kg Filter Filter surface 10 m² Filter material Pleat spun bonded polyester Number of filter elements 2 elements x 5qm Temperature range -10/ +60°C Pressure drop of elements 800-1200 Pa Pressure drop of housing 50 Pa Compressed air supply 7,3 Nm³/h with intervals of 12.5s Cleaning pulse duration 100 ms Pressure 3,7 bar Fan Type K5 Power consumption 2,2 KW Voltage 400 V, 50 Hz, 3 Phase Protection IP 55 Static pressure at the fan About 200 da Pa Fan power 2100 m³/h Weighted sound pressure levels 72 dB(A) Fitting dimensions Input stud D=220 mm Output stud D=250 mm as option Dust container 80l |
| Weight | 2500 |
