Herose - 15C01.A003.000014
Manufacturer | Herose |
---|---|
Part Number | 15C01.A003.000014 |
Inner Code | 4870065 |
Description | ball valve |
Custom Code | 84818081 |
Technical specification | DN20 BW26.9x2.0 PN100 Material: CF3M (1.4409) 3-piece ball valve DN20 PN100 oil-free and fat-free for oxygen in accordance with CGA G-4.1 2009 Leakage category “A” according to EN 12266-1 with insulation extension 305.0 mm Permissible operating temperature: -196°C to +65°C full passage ASTM A351 CF3M housing (1.4409) ASTM A479 Grade 316 Ball Ball seal: PCTFE Case seal: PCTFE with relief hole Ball valve that can be used on one side in the flow direction Inlet/ Outlet: Weld-on CF3M (1.4409) ISO 1127 RA 26.9 mm x 2.0 mm hand lever Overall length: 85.0 mm |
Please contact us to request a price quote for Herose - 15C01.A003.000014, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
