HAUFF-TECHNIK - 3030300068
| Manufacturer | HAUFF-TECHNIK |
|---|---|
| Part Number | 3030300068 |
| Inner Code | 4897715 |
| Technical specification | HSD200 SSG 1x110-162 b40 A2/EPDM55 Standard annular chamber seal for pipes with U-profile press plates with stepless super segment ring technology For sealing new or already installed Tubes/cables in core holes or feed pipes. Features: optical and tactile assembly safety thanks to built-in control opening; integrated super segment ring technology for individual Adjustment to the cable diameter on site; segments with exact diameter lettering EAN/GTIN: 4052487129022 classification: Lining pipe/core hole Di 1:200.0 mm; Design: super segment ring technology; sealing width: 40 mm; Total number of passages: 1 pc; Press plate material: A2/304L; Material connecting elements: A2 ; Press element material: EPDM55; Material combination: A2/EPDM55; FHRK standard: 40; Number of passages 1 1 ST Cable special cross section 1 110-162 |
Please contact us to request a price quote for HAUFF-TECHNIK - 3030300068, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
