HAUBER - 10970

Manufacturer	HAUBER
Part Number	10970
Inner Code	3354969
Description	vibration sensor
Custom Code	90318020
Technical specification	Schwingungsüberwachung Typ HE100 Bestellcode: HE100.01.16.01.00.00.100 nach DIN ISO 10816 ATEX-Einsatzbereich: Zone 1 / 2 / 21 / 22 ATEX-Kennzeichnung: Ex II 2 G Ex d IIC T4 Gb Ex II 2 D Ex tb IIIC T120 °C Db Frequenzbereich: 1...1000 Hz Messbereich: 0...16 mm/s Temperaturbereich: -40°C...+125°C Analogausgang: 4...20 mA Versorgungsspannung: 24V DC Gehäuse: V2A (1.4305) Edelstahl Befestigung: M8 Gewindestift Anschluss: 10m Kabel geschirmt - integriert Schutzart: IP 66/67
Weight	0.2

Please contact us to request a price quote for HAUBER - 10970, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.

WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

More products of HAUBER

10106
Vibration monitoring ATEX Type 664.16.200.0 for use in the Zone 2 and 22 Frequency range: 1 ... 1000 Hz Measuring range: 0 ... 16 mm / s - for example, Analog output: 4 ... 20 mA Supply voltage: 24 V DC Housing: V2A stainless steel Fixing: M8 threaded pin Connection: M12 Protection: IP 67
10106 SCHWINGUNGSUBERWACHUNG ATEX TYP 664.16.200.0
for use in the Zone 2 and 22 Frequency range: 1 ... 1000 Hz Measuring range: 0 ... 16 mm / s Analog output: 4 ... 20 mA Supply voltage: 24 V DC Housing: V2A stainless steel Fixing: M8 threaded pin Connection: M12 Protection: IP 67
10172
Vibration monitoring ATEX Type 664.16.100.5 for use in the zone 1 and 21 Frequency range: 1 ... 1000 Hz Measuring range: 0 ... 16 mm / s - for example, Output: 4 ... 20mA Temperature range: -20 ° C ... + 100 ° C Housing: V2A stainless steel Fixing: M8 threaded pin Connection: integrated 2m cable Protection: IP 67
10458 KABEL - 4-POLIG - 10M - GESCHIRMT
M12 socket Sheath: PUR / PVC Protection: IP67
10458 KABEL - 4-POLIG - 10M - GESCHIRMT
M12 socket Sheath: PUR / PVC Protection: IP67
10520
Cable - 4-pole - 2m - shielded M12 socket Sheath: PUR / PVC Protection: IP67
10521 5 m Kabel geschirmt
5 m cable - shielded 4-pin M12 female straight Sheath: PUR / PVC Protection: IP67
640 10 2007
vibration sensor
KABEL - 4-POLIG - 2M - GESCHIRMT
Cable - 4-pole - 2m - shielded M12 socket Sheath: PUR / PVC Protection: IP67
Art.Nr.10059 / Typ 656.A
Auswertgerät Typ 656.A / Auswertung von 1 Sensor / mit einem Schwellwert und einer Leitungsüberwachung
type 640
electric voltage
Typ 640.10.200.7
Schwingungsüberwachung ATEX Ausführung: Zone 2 und 22 / Frequenzbereich: 10...1000 Hz / Messbereich: 0...10 g peak / Analogausgang: 4...20 mA / Versorgungsspannung: 24 V DC / Gehäuse: V2A Edelstahl / Befestigung: M8 Gewindestift / Anschluss: Stecker M12 / Schutzart: IP 67
10059 / 656.A
Auswertgerät
664.16.000.0-S 10565 obsolete,replaced by Typ HE100.00.16.01.00.00.000(Art.Nr.10932)
640.64.000.0
663.64.103.0
Vibration monitoring
664.16.000.0-S 10565 -obsolete, replaced by HE100.00.16.01.00.00.000-S
664.16.000.0-S 10565
Vibration sensor including angle plug
664.16.000.0-S - obsolete, replaced by HE100.00.16.01.00.00.000-S
VIB SENSOR
T0180-05-05-03-05-02
VIB SENSOR
664.16.000.0 16 MM/S obsolete, replaced by HE100
HE100.00.16.00.00.00.000
Vibration Sensor
HE100.00.16.01.00.00.000-S
Vibration sensor
640.32.200.4
Schwingungsüberwachung Typ 640
664.16.000.0-S obsolete, replaced by HE100.00.16.01.00.00.000-S
HE100.00.16.01.00.00.000-S
Vibration sensor incl. Connector, socket
Type 664
TYP:640.16.000.0 F-NR:60316 obsolete,replaced by HE100.00.16.00.00.00.000
Vibrator Sensor
10935
Vibration Monitoring
Kabel fuer HE100.00.16.00.00.00.000
Vibration Control
