Hanovia - PureLine D 0007
| Manufacturer | Hanovia |
|---|---|
| Part Number | PureLine D 0007 |
| Inner Code | 3429446 |
| Technical specification | UV system complete with 316L stainless steel chamber, control cabinet, UV monitor, and PN16 flange connections. Design Data • Application: Disinfection • Water Type: Fresh Water • Pre-treatment: Filtration (recommended) • Design Flow Rate: 3 m³/h • UV Transmittance (T 10): 95% • UV Dose: 40 mJ/cm² (average) Technical Data – PureLine D 0007 i) Design Flow Rate 3 m³/h ii) UV Transmittance (T 10) 95% (assumed) iii) UV Dose 40 mJ/cm² (average) at the end of lamp life iv) UV Lamp Type Hanovia low-pressure amalgam lamp v) Power Consumption per Lamp 80 W vi) Number of Lamps 1 vii) Expected Lamp Life 12,000 hours viii) Chamber Material Stainless Steel 316L / 1.4404 ix) Connections 1½” (DN 40) PN16 flange x) Pressure Rating 10 bar xi) Cabinet Material Polyester coated carbon steel xii) Supply Voltage 230 V ±10% / 115 V ±10% - 50/60 Hz xiii) Standard Cable Length 5 m |
| Weight | 27 |
Please contact us to request a price quote for Hanovia - PureLine D 0007, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
