Groschopp - Typ IGKU 80-60 (WK1695101)+Typ: VE31-K-L-32 i= 12:1
| Manufacturer | Groschopp |
|---|---|
| Part Number | Typ IGKU 80-60 (WK1695101)+Typ: VE31-K-L-32 i= 12:1 |
| Inner Code | 4024722 |
| Description | GEAR MOTOR |
| Technical specification | AC ASYNCHRONOUS Type: IGKU 80-60, 380-440/220-254V, 50Hz 380-480/220-277V, 60Hz 0.36-0.38/0.62-0.66A 1360-1630U, 85W, B14, IP65, Motor wound according to WK 1695101, left/right rotation according to circuit diagram S61-0701-30, phase isolation motor, motor UR/UL conform, Motor with terminal box AK2 and 6-pin terminal board, circuit diagram in the terminal box, Motor with heat monitor 140°C as opener Connections to WAGO terminal, mounted with: SINGLE WORM GEAR Type: VE31-K-L-32 i= 12:1 n2= 113.3 rpm, M2= 4.7 Nm Service factor fB= 1.91 small flange: Ø 80 mm, flange and shaft on the left, Gear shaft: Ø 10 h6 x 29 mm long, with groove+key A3x3x20 mm according to DIN 6885 sheet 1, Painted to RAL 5002 - ultramarine blue Weight: 4.55kg Lubricant: Centoplex H/0 Fat capacity: 45+5 g Terminal box position: 34 (left) Transmission mounting position: 1 design and dimensions Drawing no.: 2017-01-003232 |
Please contact us to request a price quote for Groschopp - Typ IGKU 80-60 (WK1695101)+Typ: VE31-K-L-32 i= 12:1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
