Groschopp - IGKU 80-40
| Manufacturer | Groschopp |
|---|---|
| Part Number | IGKU 80-40 |
| Inner Code | 4267608 |
| Description | Motor |
| Technical specification | AC ASYNCRON GEARBOX MOTOR 380-440/220-254 V, 50 Hz 380-480/220-277 V, 60 Hz 0.27-0.29/ 0.47-0.50 A 2700-3250 U, 105 W, B14, IP65, Engine wound according to WK 1781301, Left/right rotation according to wiring diagram S61-0701-30, Engine UR/UL Conform, motor with phase insulation, Motor with terminal box AK2 and 6-pin clipboard, Schematic diagram in the terminal box Motor with heat switch 140°C as NC contact connections on WAGO terminal, Mounted with: SINGLE WORM GEAR UNIT Type: VE31-G-L-S i= 10:1 n2= 270 rpm, M2= 2.60 Nm Operating factor fB= 4.61 large flange: Ø 110 mm, flange and shaft left Gear shaft: Ø 12 g6 x 30 mm with groove and feather A4x20 mm according to DIN 6885 leaf1 Paint according to RAL 5002 - ultramarine blue Weight: 4,00 kg Lubricant: Centoplex H/0 Fat capacity: 60+5 g Terminal Box Position: 44 Gearbox installation: 1 Design and dimensions according to Drawing No: 2012-12-001843 Engine number: |
Please contact us to request a price quote for Groschopp - IGKU 80-40, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
