Groschopp - p/n: 501958, type: GKU 80-40B, 400/230 V, 50 Hz
| Manufacturer | Groschopp |
|---|---|
| Part Number | p/n: 501958, type: GKU 80-40B, 400/230 V, 50 Hz |
| Inner Code | 4445653 |
| Technical specification | AC ASYNCHRONOUS GEAR MOTOR 1320 U, 66 W, B14, IP65*, motor wound according to WK 1695001, left-clockwise rotation according to diagram S61-0701-31, motor with phase isolation, engine UR/UL — conform, Motor with terminal box AK2 and 8-pin clipboard, wiring diagram in terminal box, Motor with heat monitor 140°C as opener connections on WAGO terminal, with brake for 205 V, 5.0 Nm, WK 1775300, and built-in rectifier, switched to terminal board, supply voltage 230 V 50 Hz, mounted with: PLANETARY GEARBOX type: PLG 52/B14-2 i= 13, 73:1 n2 = 96.1 rpm, M2 = 4.9 Nm Operating factor fB= 2.45 Transmission shaft: Ø 12 mm h7 x 25 mm long with groove+feather key 4x4x16mm according to DIN 6885 sheet 1 with axial thread M4 x 10mm according to DIN 332 sprocket black chromated Terminal box location: 41 Gear attachment: 1 Design and dimensions according Drawing no.: 2012-10-001795 Engine number: * transmission in protection class IP54 |
Please contact us to request a price quote for Groschopp - p/n: 501958, type: GKU 80-40B, 400/230 V, 50 Hz, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
