Grob - MC25-GL-F-1F-GK-0350-0000-TR100x16-b-2FR-OM-S
| Manufacturer | Grob |
|---|---|
| Part Number | MC25-GL-F-1F-GK-0350-0000-TR100x16-b-2FR-OM-S |
| Inner Code | 550008 |
| Description | WORM GEAR SCREW JACK |
| Custom Code | 84254900 |
| Technical specification | MC25-GL-F-1F-GK-0350-0000- TR100x16-B-2FR-OM-S [1.00 piece] Classic screw jacks Installation size: MC25 load: 250 kN static Type: G Version: F Installation position: 1F Gear ratio: L 32:1 Stroke per revolution of the drive shaft: 0.5 mm stroke: 350 mm Spindle extension: VL = 0 mm Lifting spindle: TR100x16 reinforced Head: GK Drive shaft end: on both sides Installation dimensions from housing screw-on surface to (center hole) GK head retracted: 359 mm Thermowell: round Guide ring: with second guide ring Engine mounting side: without motor Primer: red-brown Special versions: - reinforced spindle TR100x16 - incl. bellows - including anti-rotation device Temperature monitoring: Self-closing Measuring point for limit value monitoring (+82°C) |
| Weight | 1 |
Please contact us to request a price quote for Grob - MC25-GL-F-1F-GK-0350-0000-TR100x16-b-2FR-OM-S, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
