GIORDANO COLOMBO - GCG200174-3,4
| Manufacturer | GIORDANO COLOMBO |
|---|---|
| Part Number | GCG200174-3,4 |
| Inner Code | 4014018 |
| Technical specification | S/N: 1800973 Colombo Spindle Motor - RC 73/22 25 FP1 ISO 20 CR PD SF 3 HP, 2.2 kW, 460 V, 4 A, 24000/40000 RPM, 400/667 Hz, 2 Pole, Dwg #G200174_02 FEATURES -Cooling by compressed air -Automatic tool change with pneumatic actuator -Equipped with 2 inductive sensors for tool change control (S3 - tool presence & S2 - actuator forward) - 4mm PNP -Equipped with 2 inductive sensors for tool change control (S1 - shaft stop & S4 - actuator home) - 5mm PNP -Shaft taper for ISO 20 -Copper rotor for greater electrical efficiency and cooler operation -Pressurization of spindle nose and winding cavity -Pneumatic cone clean -Quiet operation (max 72 dBA at top speed) -Dual angular contact bearings front and rear -Ceramic bearings -Weight 22.5 lbs (10.2 kg) |
Please contact us to request a price quote for GIORDANO COLOMBO - GCG200174-3,4, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
