Georgin - DFML6CX

Manufacturer Georgin
Part Number DFML6CX
Inner Code 3355997
Description Diff.pressure switch F series
Custom Code 90322000
Technical specification protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 0 to 40 mbar min/max static pressure : +/- 300 mbar sensing element : diaphragm BunaN material : BunaN - 304L st. st. flange process connection : 1/2""GM switch : 1 tropicalized SPDT adjust. deadband : <3,8 to 20 mbar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10) article reference: 0FD06BCMY0000 country of origin: France / U.E.
Weight 2.5

Please contact us to request a price quote for Georgin - DFML6CX , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Georgin-DFML6CX price

More products of Georgin

  • 0FD06BMJX0200 REF. DFMS6MX

    Diff.pressure switch F series protection : IP66 housing : mazak, epoxy painted range : 50 to 1000 mbar min/max static pressure : 0 / 80 bar sensing element : diaphragm BunaN material : BunaN - 316L st. st. flange process connection : 1/4"NPTF switch : 1 tropicalized SPDT adjust. deadband : <90 to 200 mbar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)

  • 0FP04BKSA00A0 REF. FP4K

    Pressure switch F series protection: IP66 hosuing: mazak, epoxy painted-st.st. screws range: -1 to 5 bar max. pressure : 13 bar sensing element : bellows materila: bronze process connection : 1/2"GM switch: 1 tropicalized SPDT fixed deadband : <165 mbar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10) features: st. st. tag plate Origin of material: FRANCE / E.U. European Customs Tariff Pressure Switch : 9032 2000

  • 0FP06BPSY0000

    Ref. FP6PX 1 296,00 296,00 Pressure switch F series protection : IP66 housing : mazak, epoxy painted-st.st. screws range : 0.5 to 10 bar max. pressure : 15 bar sensing element : bellows material : 316L st. st. process connection : 1/2"GM switch : 1 tropicalized SPDT adjust. deadband : <0,24 to 2 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)

  • 0FP06BPSY03A0

    Ref. FP6PX Pressure switch F series protection: IP66 housing: mazak, epoxy paunted-st.st. screw range: 0.5 to 10 bar max. pressure: 15 bar sensing element: bellows material: 316: st.st. process connection: 1/2" NPTM switch: 1 tropicalized SPDT adjust. deadband: <0,24 to 2 bar current rating: 10A/240VAC - 0.5A/110VAC vcable gland: polyamid M16 (Ø5-10) features: st.st.tag plate Goods of French/ E.U. origin European Customs Tariff Pressure Switch: 9032 2000 Aproximative gross weight: 3 kg

  • 0FP06BPSY03A0

    Ref. FP6PX Pressure switch F series Protection: IP66 housing: mazak, epoxy painter-st.st. screws range: 0.5 to 10 bar max. pressure: 15 bar sensing element: bellows material: 316L st.st. process connection: 1/2"NPTM switch: 1 tropicalized SPDT adjust. deadband: <0,24 to 2 bar current rating: 10A/240VAC - 0.5A/110VDC cable gland: polyamid M16 (Ø5-10) features: st. st. tag plate Goods of French / E.U. origin European Customs Tariff Pressure Switch: 9032 2000

  • 0FP06BRSX0300 REF. FP6RX

    Pressure switch F series protection : IP66 housing : mazak, epoxy painted range : 5 to 50 bar max. pressure : 80 bar sensing element : bellows material : 316L st. st. process connection : 1/2"NPTM switch : 1 tropicalized SPDT adjust. deadband : <1,4 to 10 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)

  • 0FP06BVLX0300 REF. FPL6VX

    Pressure switch F series protection : IP66 housing : mazak, epoxy painted range : 25 to 400 bar max. pressure : 600 bar sensing element : Bourdon tube material : 316Ti st. st. process connection : 1/2"NPTM switch : 1 tropicalized SPDT adjust. deadband : <32 to 200 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10)

  • 0FP54BQSX0300 REF. FP54QX

    (Pressure switch F series protection: IP66 housing: mazak, epoxy painted range: 2.5 to 25 bar max. pressure : 30 bar sensing element : bellows material: 316L st. st. process connection : 1/2"NPTM switch: 2 separate tropicalized SPDT adj. from : <0,6 to 5 bar current rating : 10A/240VAC - 0.5A/110VDC cable gland : polyamid M16 (Ø5-10) )

  • 0PD06BCB00200 REF. DMPB6M11

    Diff.pressure switch P series protection : IP66 housing : mazak, epoxy painted range : 2 to 40 mbar max. static pressure : 3 bar sensing element : diaphragm BunaN material : BunaN - mazak flange process connection : 1/4"NPTF switch : 1 SPDT, dry contact adjust. deadband : <11 to 30 mbar current rating : 5A/240VAC - 0.5A/110VDC cable gland : polyamid M20 (Ø7.5-13)

  • 17A2E4

    Intrinsically Safe Control

  • BVNS0B00-00-00

    Insulator 230V AC, input/output 4-20mA

  • bzg788+

    Zener Barriere

  • BZG796

    Zener diode

  • FC 54T

    range: 115-210 °C sensing element: 2 m capillary- bulb 9 mm diameter, 120 mm length, copper

  • FC6GXRTPF

    Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : -20 to +45 ºC max. temperature : 55 ºC sensing element : 4m capillary-bulb Ø14x150mmmaterial : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)4-20ºC/1-7ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate

  • FC6PXRTPF

    Capillary temperature switch F series protection : IP66 / ATEX flame proof housing : Ex-proof in epoxy painted-st.st. screws range : 20 to 95 ºC max. temperature : 105 ºC sensing element : 4m capillary-bulb Ø14x150mm material : 316Ti st. st. capillary protection : st. st. armor switch : 1 tropicalized SPDT adjust. deadband :(low/high of range)5-25ºC/1-8ºC current rating : 10A/240VAC - 0.5A/110VDC cable gland : as option (elect. connect. 3/4"NPTF) features: Ex d st. st. tag plate

  • FP4DRX

    Pressure switch F series protection : IP66 / ATEX intrinsic safety housing : mazak, epoxy painted range : 5 to 50 bar max. pressure : 80 bar sensing element : bellows material : 316L st. st.

  • FP4K, Art. N: 0FP04BKS00000

    Pressure switch F series

  • FP54QX

    Pressure switch

  • FP62P

    Pressure switch F series

  • GR5000S00 (0/50 BAR)

    (Gauge pressure transmitter... GR/GA series housting: stainless steel / protection: IP65 range : 0...50 bar maxi pressure : 150 bar sensor: ceramic cell on viton gasket process connection : 1/2" BSPM - st.st. 316 L electrical connector : DIN43650 power supply : 10...30Vdc output signal : 4...20 mA max. global error : 0.5% FS --------ATEX information------------ EC type examination certificate LCIE 01 ATEX 6137X Ex ia IIC T6 or T5 Ga (-30 Ta 55 or 70Celsius) Ex ia IIIC T80Celsius or T95Celsius Da (-30 Ta 55 Celsius or 70 Celsius Groupe II - category 1GD - Zones 0-1-2 or 20-21-2: Ex ia I - group I (MInes) -CAtegory Mi Production Notification LCIE 02 ATEX Q 8023 See leaflet for a safe use)

  • GR7000S00

    Drucktransmitter

  • GRE000S00

    Drucktransmitter

  • GRK000S00

    Drucktransmitter

  • OFP06BPSYO3A0 (FP6PX)

    SWITCH PRESSURE

  • P16AX40A6

    (Pressure switch)
