Gemü - 88618339 / D458100W225G514U5 AEJ4C55

Manufacturer Gemü
Part Number 88618339 / D458100W225G514U5 AEJ4C55
Inner Code 4952908
Description Electric butterfly valve
Custom Code 84818085
Technical specification Type D458 butterfly valve, actuated by an electric motor DN 100 DN 100 housing type W intermediate flange design (wafer), FTF EN 558 series 20 construction length Operating pressure 2 10 bar Connection type 2 PN 10/flange EN 1092, installation length FTF EN 558 series 20 Housing material 5 PP, reinforced G5 PP-H disc material Seal material 14 EPDM Voltage/frequency U5 24V-240V AC/DC for model 20, 35, 55, 85, 140, 300 AE ON/OFF drive control module, 2 additional potential-free limit switches, Clase A (EN15714-2) Drive version J4C55 drive, electric motor, operating time 13s, torque 55Nm, J+J, type J4 heater, IP67 The following documentation is part of the order item 2.1 Factory certificate 2.2 Certificate of operability

Please contact us to request a price quote for Gemü - 88618339 / D458100W225G514U5 AEJ4C55, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Gemü-88618339 / D458100W225G514U5 AEJ4C55 price
