Gemü - 687 40D88405M1H/N 1502 / 88702602
| Manufacturer | Gemü |
|---|---|
| Part Number | 687 40D88405M1H/N 1502 / 88702602 |
| Inner Code | 4700306 |
| Description | diaphragm valve |
| Custom Code | 8481 8087 |
| Technical specification | Type 687 diaphragm valve, pneumatically operated, plastic drive, stainless steel connector DN 40 DN 40 Housing type D two-way body connection type 88 clamp ASME BPE, for ASME BPE pipe, FTF EN 558 series 7, overall length, Overall length only for housing type D Valve body material 40 1.4435 (F316L), forged body Membrane material 5M PTFE/EPDM in two parts Control function 1 Closed in rest position (NC) Drive type H/N Drive size H/N Design type 1502 Ra ≤ 0.8 μm (30 μin.) for surfaces in contact with the media, in accordance with DIN 11866 H3, Mechanically polished interior Membrane size 40 Membrane size 40 The following documentation is part of the order item 3.1 Inspection certificate ¹ 2.2 Factory certificate printing 2.2 Factory certificate roughness (RA) 2.1 Factory certificate EU declaration of conformity FDA Declaration of Conformity |
Please contact us to request a price quote for Gemü - 687 40D88405M1H/N 1502 / 88702602, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
