Fuji - FKCT33V6-2AKBY-5L
| Manufacturer | Fuji |
|---|---|
| Part Number | FKCT33V6-2AKBY-5L |
| Inner Code | 4834374 |
| Custom Code | 9026 2020 |
| Technical specification | FKC series differential pressure transmitter Measuring cell with microcapacity sensor Zero point and span independent adjustable Min/max span limit: 0... 3.2 - 320 mbar Static pressure: -1/160 bar Accuracy: +/- 0.065% of calibrated span Process connection: 1/4” — 18 NPT Measuring membrane: 316L st.st. Measuring cell filling: silicone oil Flange: 316 stainless steel Viton process lid seal Oval flange connection: 7/16-20 UNF Screws: 316L st. st. (M10), other parts in contact with medium 316 inox Power supply: 10.5 to 45 VDC Electrical connection: 1/2" - 14 NPT Output signal: 4... 20 mA (two-wire Technology) + HART RFI protection (in accordance with IEC 801-3) Housing: die-cast aluminum with polyester coating equipped with a digital display with push buttons Additionally: stainless steel nameplate equipped with st.st. -Fixing clamp for 2-inch pipe mounting |
Please contact us to request a price quote for Fuji - FKCT33V6-2AKBY-5L, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
