Fuji - FKCT22V5-AACYY-AA
| Manufacturer | Fuji |
|---|---|
| Part Number | FKCT22V5-AACYY-AA |
| Inner Code | 3433426 |
| Custom Code | 9026 2020 |
| Technical specification | 83042 Diferential pressure transmitter FKC-series Smart, 4-20 mA dc + Fuji/HartTM digital signal Process connections : 1/4-18 NPT Oval flange connection : 7/16-20 UNF Electrical connection : 1/2-14 NPT Enclosure type : L shape Span : 10 / 600 mmWC Measuring diaphragm : 316L SS HP process cover : 316L SS and BP process cover : 316L SS Wetted cell body : 318LN SS Indicator : none Approvals (Note 1) : None Side vent : None Mounting bracket : Yes, SS 304L TAG plate : None SS housing : None Special applications : none (std) Fill fluid : silicone oil Process cover gasket : Viton Bolts / Screws : Carbon steel Cr-Mo (standard) M10 for static pressure < 160 bar article reference: FKCT22V5-AACYY-AA customs code: 9026 2020 country of origin: France / U.E. Gewicht ca. 3 kg / Stück |
| Weight | 3 |
