Fuji - FKCP11V5-2AFYY-CU
Manufacturer | Fuji |
---|---|
Part Number | FKCP11V5-2AFYY-CU |
Inner Code | 3433425 |
Custom Code | 9026 2020 |
Technical specification | 83041 Differential pressure transmitter FKC-Series Smart, 4-20 mA dc + Fuji/HartTM digital signal Process connections : 1/4-18 NPT Oval flange connection : M10 Electrical connection : 1/2-14 NPT Enclosure type : L shape Span : 10 / 100 mmWC Measuring diaphragm : 316L SS HP process cover : 316L SS and BP process cover : 316L SS Wetted cell body : 318LN SS Indicator : digital, Custom scale with push-button Approvals: None Side vent : Yes Mounting bracket : Yes, SS 304L TAG plate : None SS housing : None Special applications : none (std) Fill fluid : silicone oil Process cover gasket : PTFE square section gasket in SS flange (FEF design) Bolts / Screws : SS 316/316 (bolt/nuts) M10 for static pressure < 160 bar No approval for use in hazardous area article reference: FKCP11V5-2AFYY-CU customs code: 9026 2020 country of origin: France / U.E. Gewicht ca. 3 kg / Stück |
Weight | 3 |
Please contact us to request a price quote for Fuji - FKCP11V5-2AFYY-CU, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
