Fristam - FZ 20 KF / 0545000001
| Manufacturer | Fristam |
|---|---|
| Part Number | FZ 20 KF / 0545000001 |
| Inner Code | 5048756 |
| Description | FZ 20 KF self-priming centrifugal pump |
| Custom Code | 84137045 |
| Technical specification | Pump on the KF bearing rack Pump material: 1.4404 (316L) Shaft sealing: 649/2 (2H5V2/2H5V2) 1. FKM bellows coal/cast chrome/FKM 2. FKM bellows coal/cast chrome/FKM Elastomers: FKM with FDA certification Connection type: DIN 11851 Suction side: DN 50 Pressure side: DN 50 Engine: 7.5 kW, n = 1450 rpm 50 Hz, ISO class: F Voltage 400/690V IP 55 Funding dates: product = - Certificates/Exams: Documentation exclusively in accordance with Fristam standards, unless otherwise confirmed. - FDA certification/EC1935/2004 - standard dimension sheet Generally: - special paint RAL 9007/gray aluminum engine: - supplier (see below) - IEC132M motor size - Terminal box location: above - with cold conductor temperature sensor - according to efficiency class IE3 pump head: - Connections: DIN 11851 thread connectors - Pump head turned 90° to the left - suction side at the bottom, pressure side at the top (looking at the pump cover) Shaft sealing: - GLRD: double-acting Rinsing water pressure max. 0.2 bar - independent of the direction of rotation incl. flush water connection with G1/8" pipe other agreements: Engine brand SEW, type DRN multi-range voltage Voltage range 50 Hz: 380-400 V triangle/660-690 V star Voltage range 60 Hz: 440-460 V triangle Voltage tolerance +/- 10% Both areas are stamped on the type plate. Pump with housing heating jacket G3/8" - Terminal box at the top - Motor with holder feet Pump like S/No.: 0545 71 0170 |
Please contact us to request a price quote for Fristam - FZ 20 KF / 0545000001, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
