Fristam - FZ 20 B / 0545000001
| Manufacturer | Fristam |
|---|---|
| Part Number | FZ 20 B / 0545000001 |
| Inner Code | 5048757 |
| Description | Self-priming centrifugal pump FZ 20 B |
| Custom Code | 84137045 |
| Technical specification | pump with motor base Pump material: 1.4404 (316L) Shaft sealing: 404B/1 (2H2P2) FKM bellows coal/ceramic/NBR Elastomers: NBR with FDA certification Connection type: DIN 11851 Suction side: DN 50 Pressure side: DN 50 Engine: 5.5 kW, n = 1450 rpm 50 Hz, ISO class: F Voltage 400/690V IP 55 Funding dates: product = - Certificates/Exams: Documentation exclusively in accordance with Fristam standards, unless otherwise confirmed. - FDA certification/EC1935/2004 - standard dimension sheet Generally: - special paint RAL 9007/gray aluminum engine: - Special motor: engine size 132S - Terminal box location: - with cold conductor temperature sensor - according to efficiency class IE3 pump head: - Connections: DIN 11851 thread connectors - suction side left, pressure side right (looking at the pump cover) Shaft sealing: - GLRD: simple-acting - independent of direction of rotation other agreements: - Terminal box at the top - Motor with holder feet Pump like S/No.: 0545 71 0115 |
Please contact us to request a price quote for Fristam - FZ 20 B / 0545000001, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
