Fristam - FZ 17 KF / 0540000001
| Manufacturer | Fristam |
|---|---|
| Part Number | FZ 17 KF / 0540000001 |
| Inner Code | 5048758 |
| Description | Self-priming centrifugal pump FZ 17 KF |
| Custom Code | 84137045 |
| Technical specification | Pump on the KF bearing rack Pump material: 1.4404 (316L) Shaft sealing: 649/2 (2H5V2/2H5V2) 1. FKM bellows coal/cast chrome/FKM 2. FKM bellows coal/cast chrome/FKM Elastomers: FKM with FDA certification Connection type: DIN 11851 Suction side: DN 50 Pressure side: DN 50 Engine: 2.2 kW, n = 1450 rpm 50 Hz, ISO class: F Voltage 230/400V IP 55 Funding dates: product = - Certificates/Exams: Documentation exclusively in accordance with Fristam standards, unless otherwise confirmed. - FDA certification/EC1935/2004 - standard dimension sheet Generally: - special paint RAL 9007/gray aluminum engine: - supplier (see below) - IEC100L motor size - Terminal box location: above - with cold conductor temperature sensor - according to efficiency class IE3 pump head: - Connections: DIN 11851 thread connectors - Pump head turned 90° to the left - suction side at the bottom, pressure side at the top (looking at the pump cover) Shaft sealing: - GLRD: double-acting Rinsing water pressure max. 0.2 bar - independent of the direction of rotation incl. flush water connection with G1/8" pipe other agreements: Pump as pre-delivered S/No.: 0540 71 0101 Motor voltage: motor made by SEW, multi-range voltage Voltage range 50 Hz: 220-230 V triangle/380-400 V star Voltage range 60 Hz: 254-266 V triangle/440-460 V star Voltage tolerance +/- 10% Both areas are stamped on the type plate. Pump with housing heating jacket G 1/4" |
Please contact us to request a price quote for Fristam - FZ 17 KF / 0540000001, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
