Fristam - FPE 742/175 B
| Manufacturer | Fristam |
|---|---|
| Part Number | FPE 742/175 B |
| Inner Code | 4787073 |
| Description | Pump |
| Custom Code | 84137051 |
| Technical specification | pump with motor base Pump material: 1.4404 (316L) Shaft seal: 9.468A (2V21V2) SIC/SIC/FKM Elastomers: FKM with FDA certificate Connector Type: Tri-Clamp Suction side: 2.5" Print side: 2" Impeller diameter: 175 mm Motor: 4.0kW, n=2900 rpm 50 Hz, ISO class ISO: F Voltage 400/690V IP 55 Funding dates: Product = unknown Certificates/tests: Documentation exclusively in accordance with Fristam standards, if not otherwise confirmed. - Factory certificate “2.1" - FDA certificate/EG1935/2004 - standard measurement sheet In general: - Alexit No. 91 pure silver finish - Areas in contact with the product for --> housing, cover, impeller, impeller nut <= RA0.8μm Electropolished impeller engine: - IEC112M motor size - Terminal box location: above - with cold conductor temperature sensor - according to efficiency class IE3 Pump head: - with housing drain clamp (Ø12.70x1.65) - 90° front bend looking at the pump cover Shaft seal: - GLRD: simple-acting other agreements: Same as SN 0444 74 0303 |
Please contact us to request a price quote for Fristam - FPE 742/175 B, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
