Fristam - FP 722/130 VC
| Manufacturer | Fristam |
|---|---|
| Part Number | FP 722/130 VC |
| Inner Code | 4981851 |
| Custom Code | 84137051 |
| Technical specification | 0424000001 alternatively with IEC standard motor FP 722/130 VC centrifugal pump pump with dome Pump material: 1.4404 (316L) Shaft sealing: 9.665 (2N5E3/2N5E3) 1. carbon/cast chrome/EPDM 2. carbon/cast chrome/EPDM Elastomers: EPDM alcohol resistant with FDA certification Connection type: DIN 11851 Suction side: DN 50 Pressure side: DN 40 Funding dates: Product = condensate 7.7 m³/h versus 30 m Fls Temperature = 55°C Inlet height: 2.0 m required drive power 1.8 kW Motor produces 2.4 kW at 440 V Marking: - on durable stainless steel plate F1B1G10 Certificates/Exams: Documentation exclusively in accordance with Fristam standards, unless otherwise confirmed. - FDA certification/EC1935/2004 In general: - Alexit No. 91 pure silver finish engine: - IEC90L engine size - Terminal box location: above - with cold conductor temperature sensor - according to efficiency class IE3 - suitable for frequency converter operation Control range 25-60 Hz pump head: - Connections: DIN 11851 thread connectors Shaft sealing: - GLRD: double-acting Rinsing water pressure max. 0.2 bar incl. flush water connection with G1/8" pipe other agreements: Motor voltage: 250/440 V |
Please contact us to request a price quote for Fristam - FP 722/130 VC, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
