Fristam - FL 100L (0692000020)
| Manufacturer | Fristam |
|---|---|
| Part Number | FL 100L (0692000020) |
| Inner Code | 1325603 |
| Description | Positive Displacement Pump |
| Technical specification | Rotary lobe pump FL 100L Pump on base frame 1.4301 with coupling and coupling protection Pump material : 1.4404 (316L) Displacer : 1.4404 (316L) Shaft seal : 1001/1 (2K10E3/V) 1. Carbide/Carbide/EPDM 2. FKM Elastomers : EPDM alcohol resistant Connection type : DIN 11851 left : DN 80 right : DN 80 Drive : SK32-132MP Output speed: n = 330 rpm 7.5kW, n = 1450 rpm 50Hz, ISO: F, IP 55 Voltage 400/690V Funding dates: Product: fruit juice concentrate Flow rate = 15 m³/h Temperature = 15 °C --- differential pressure = max. 8 bar Viscosity = 350 mPa*s --- Density = 1.35 kg/l Certificates / exams: - QH characteristic at the operating point (FU) - Standard dimension sheet General: - Horizontal pump - Upper drive shaft - Pump with elastic coupling pump head: - Connections: threaded connector DIN 11851 shaft seal: - GLRD: flushed Sealing water pressure max. 0.2 bar incl. seal water connection with pipe Drive: - Transmission supplier: NORD - with PTC thermistor - according to efficiency class IE3 other agreements: Marking 3610PCE01 |
| Weight | 200 |
Please contact us to request a price quote for Fristam - FL 100L (0692000020), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
