Fristam - FKFHSV 40
| Manufacturer | Fristam |
|---|---|
| Part Number | FKFHSV 40 |
| Inner Code | 4865258 |
| Custom Code | 84136080 |
| Technical specification | Pump standing on gear base Pump material: 1.4404 (316L) Displacer: SE Wave sealing: 128c (2K10V2/V) 1. Tungsten carbide/carbide/FKM 2. FKM Elastomers: FKM with FDA certification Connection type: DIN 11864-NF-A above for pipes in accordance with DIN 11866 A DIN 11864-GS-A below for pipes in accordance with DIN 11866 A above: DN 65 bottom: DN 50 Drive: SK33-SP-112MP Output speed: n = 133 rpm 4.0 kW, n = 1450 rpm 50Hz, ISO:F, IP55 Voltage 400/690V Product: - Certificates/Exams: Documentation exclusively in accordance with the Fristam standard, if not otherwise confirmed. - QH characteristic at operating point (FU) 1 operating point - FDA certification/EC1935/2004 - certified size sheet Generally: - Vertical pump - pump with directly flanged gear motor - drive shaft on the right - seen from the front of the pump cover - Special paint RAL 9007/gray aluminum - Gearbox with USDA H1 approved oil Pump head: - Top connection: DIN 11864-NF-A groove flange for pipes in accordance with DIN 11866 A - Bottom connection: DIN 11864-GS-A thread socket for DIN pipes 11866 A (seen from the front of the pump cover) - Temperature displacer - with lid liner Shaft sealing: - GLRD: rinsed Rinse water pressure max. 0.2 bar incl. rinse water connection with pipe Drive: - Transmission supplier: NORD - with external fan suitable for: single-phase operation (stonemason circuit) 230-277V, 50Hz + 60Hz and three-phase operation (triangle/star circuit) 220-290V/380-500V, 50Hz 220-332V/380-575V, 60Hz - with PTC conductor temperature sensor - according to efficiency class IE3 - suitable for frequency converter operation Control range 5-100Hz - Transmission with oil according to USDA H1 approval other arrangements: Terminal box on the left when looking at the pump cover Connections: upper suction side DN 65, with additional CIP connection, lateral, DN 50, with welded-on pneumatic disc valve rectangular inlet to the pump, 80 x 50 mm Distance between the center of the pump and the top of the socket 212 mm print pages below, DN 50 Distance between the center of the pump and the top of the socket 153 mm Barrier water tube art. No. 0915 61 0648 |
Please contact us to request a price quote for Fristam - FKFHSV 40, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
