Foxboro - IAP10-D20C1F-M2L1 / Cert-D / Cert-E
| Manufacturer | Foxboro |
|---|---|
| Part Number | IAP10-D20C1F-M2L1 / Cert-D / Cert-E |
| Inner Code | 3761261 |
| Description | Pressure Transmitter |
| Technical specification | Intelligent Absolute Pressure Transmitter IAP10 FUNCTION: Measures pressure and transmits a proportional electrical signal. D ELECTRONIC VERSION AND OUTPUT SIGNAL: Intelligent; digital FoxCom or 4 to 20 mA, configurable 20 STRUCTURE CODE MATERIALS AND TYPE: 316L SS process connection, Co-Ni-Cr diaphragm, silicone fill fluid, 1/2 NPT external and 1/4 NPT internal thread connection type C SPAN LIMITS: 0.007 and 0.21 MPa, 1 and 30 psi, 0.07 and 2.1 bar or kg/cm2 1 CONDUIT CONNECTION AND HOUSING MATERIAL: 1/2 NPT conduit connection, both sides, aluminum housing F ELECTRICAL SAFETY: FM intrinsically safe for Class I, Division 1, Groups A, B, C, D; Class II, Division 1, Groups E, F, G; and Class III, Division 1. Also Class I, Division 2, Groups A, B, C, D; Class II, Groups F, G; and Class III, Division 2. Explosionproof for Class I, Division 1, Groups B, C, D; dust-ignitionproof for Class II, Division 1, Groups E, F, G; and Class III, Division 1. M2 OPTIONAL MODEL SUFFIX INCLUDED: 316 SS bracket with stainless steel bolts for use with 1/2 NPT L1 OPTIONAL MODEL SUFFIX INCLUDED: Digital indicator, internal pushbuttons, and window cover Cert-D QUALITY ASSURANCE CERTIFICATE: Material certificate; the certificate lists the instrument process wetted metallic parts by material, part number, and description of piece part. The material certificates are included and it states that the instrument conforms to BS EN 10204-3.1 (formerly (DIN 50049-3.1B). When the instrument includes an accessory item of manifold valve assembly, IFO/IFOU integral orifice, or a pressure seal, specified by use of an AS Reference or linked model code, the certificate applies to both, the instrument and the accessory. Cert-E QUALITY ASSURANCE CERTIFICATE: Calibration Certificate; the certificate shows calibration data for the instrument along with statement that calibration test equipment used is traceable to the National Institute of Standards and Technology (NIST). NIST was formerly known as the National Bureau of Standards (NBS). |
| Weight | 5 |
Please contact us to request a price quote for Foxboro - IAP10-D20C1F-M2L1 / Cert-D / Cert-E, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
