Foxboro - 84CF030-TPRF1STSVJYY-LN
| Manufacturer | Foxboro |
|---|---|
| Part Number | 84CF030-TPRF1STSVJYY-LN |
| Inner Code | 4969180 |
| Technical specification | Harmonize number: 9026.10.2040 84CF030 NOMINAL LINE SIZE: 3-inch (DN 80) PROTOCOL TYPE: Smart, TOUGH PULSE OUTPUT: Standard, Pulse Output Capability BODY AND FLANGE MATERIAL: Only with CF8M (316) Cast Body/Shedder and Type 316 Flanges (Line Sizes 84CF008 (3/4") to 84CF040 (4")) and Type 304 SS Flanges (Line Sizes 84CF060 (6") to 84CF080 (8")). {\ par} END CONNECTIONS: ANSI Class 150 Flange RF SINGLE OR DUAL MANIFOLD & INSULATION MANIFOLD: Single measurement, no insulation manifold MULTI-VARIABLE SELECTIONS Temperature only (up to 500 F, 260 C) SENSOR FILL, TEMPERATURE RANGE, AND MATERIAL: Silicone Fill, Standard Temp -20° to +200°C (0° to 400°F), Stainless Steel Type CF3M {\ par} MOUNTING/CONDUIT OPENINGS FOR ELECTRONIC HOUSING: Integrally Mounted to Flowtube; M20 Conduit Connection, Aluminum Housing {\ par} LOCAL DIGITAL INDICATOR/CONFIGURATOR: Full Function ELECTRICAL CERTIFICATION: No agency electrical certification, with CE Mark, PED Controls and Records {\ par} OPTIONAL MODEL SUFFIX (ES) INCLUDED: Standard Certificate of Compliance OPTIONAL MODEL SUFFIX (ES) INCLUDED: Foxboro Calibration and Pressure Test Certification {\ par} |
Please contact us to request a price quote for Foxboro - 84CF030-TPRF1STSVJYY-LN, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
