Foxboro - 244LD-SS3R1RNMHZZZ-ML12
| Manufacturer | Foxboro |
|---|---|
| Part Number | 244LD-SS3R1RNMHZZZ-ML12 |
| Inner Code | 3362408 |
| Description | Intelligent Buoyancy Transmitter with Torque Tube |
| Technical specification | Intelligent Buoyancy Transmitter with Torque Tube 244LD FUNCTION: Intelligent transmitter designed to perform measurements for liquid level, interface or density of liquids. The measurement is based on the Archimedes buoyancy principle. S WAFER BODY MATERIAL (process wetted): 1.4404 equivalent to 316L / 1.4435, application from -60 … +400 °C S TORQUE TUBE MATERIAL (process wetted): 1.4404 equivalent to 316L 3 WAFER BODY FLANGE SIZE: 3-inch R1 WAFER BODY PRESSURE RATING AND CONTACT FACE: ANSI class 150 form raised face / raised face R WAFER BODY MOUNTING DIRECTION (amplifier to body): Right hand mounted N VERSION: Base version Levelstar 244LD M CABLE ENTRY: M20 x 1.5 without cable gland H COMMUNICATION: HART ZZZ ELECTRICAL CLASSIFICATION: For general purpose areas, not explosionproof M OPTIONAL MODEL SUFFIX INCLUDED: External pushbuttons for maintenance L OPTIONAL MODEL SUFFIX INCLUDED: Tag no. labeling; stainless steel label fixed with wire 1 CERTIFICATION: Certificate of compliance acc. to EN 10204-2.1 2 CERTIFICATION: Calibration certificate acc. to EN 10204-2.2 (specific test report) |
| Weight | 1 |
Please contact us to request a price quote for Foxboro - 244LD-SS3R1RNMHZZZ-ML12, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
