Foxboro - 244LD-CX3R2RNNHD1C-HM4L236Q8
| Manufacturer | Foxboro |
|---|---|
| Part Number | 244LD-CX3R2RNNHD1C-HM4L236Q8 |
| Inner Code | 3409716 |
| Description | Intelligent Buoyancy Transmitter |
| Custom Code | 9026.1000 |
| Technical specification | with Torque Tube 244LD FUNCTION: Intelligent transmitter designed to perform measurements for liquid level, interface or density of liquids. The measurement is based on the Archimedes Buoyancy Principle. C WAFER BODY MATERIAL (Process Wetted): Hastelloy C276, application from -196°C to +400°C X TORQUE TUBE MATERIAL (Process Wetted): Hastelloy C276 3 WAFER BODY FLANGE SIZE: 3 inch R2 WAFER BODY PRESSURE RATING AND CONTACT FACE: ANSI Class 900 (300/600/900) Form Raised Face / Raised Face R WAFER BODY MOUNTING DIRECTION: (Amplifier To Body Right Hand mounted N VERSION: Base VERSION LEVELSTAR - (244LD) N CABLE ENTRY: 1/2-14 NPT without cable gland H COMMUNICATION: HART D1C ELECTRICAL CLASSIFICATION: ATEX Explosionproof, Zone 1, IIC T6 H OPTIONAL MODEL SUFFIX(ES) INCLUDED: Housing complete stainless steel M OPTIONAL MODEL SUFFIX(ES) INCLUDED: External Pushbuttons for Maintenance 4 OPTIONAL MODEL SUFFIX(ES) INCLUDED: PED 97/23/EC additional unit verification, according to module F/G 0 … 100% L OPTIONAL MODEL SUFFIX(ES) INCLUDED: Tag No. Labeling - stainless steel label fixed with wire 2 OPTIONAL MODEL SUFFIX(ES) INCLUDED: EN 10204-2.2 Specific Test Report (Calibration) 3 OPTIONAL MODEL SUFFIX(ES) INCLUDED: EN 10204-3.1 Inspection Certificate of Process Wetted Metallic Material 6 OPTIONAL MODEL SUFFIX(ES) INCLUDED: Comply With NACE Standard MR-01-75 C, H, I, J. N, Q, S, T, U, K, L, O, P, R Q OPTIONAL MODEL SUFFIX(ES) INCLUDED: SIL 2 8 OPTIONAL MODEL SUFFIX(ES) INCLUDED: Dye Penetration Test 2 Calibrated Range 0 To 100 % 2 Lower Density to be announced by customer upon award of order 2 Upper Density to be announced by customer upon award of order 2 Tag No. Labeling-L to be announced by customer upon award of order |
| Weight | 18 |
Please contact us to request a price quote for Foxboro - 244LD-CX3R2RNNHD1C-HM4L236Q8, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
