Foxboro - 204DE-SSD6KS2-L13
| Manufacturer | Foxboro |
|---|---|
| Part Number | 204DE-SSD6KS2-L13 |
| Inner Code | 3411119 |
| Description | Displacer Element |
| Custom Code | 9026.10 |
| Technical specification | PSS Reference: EML0901 A-EN Displacer for Buoyancy Transmitters from 2N buoyancy up to 20N RANGE OF APPLICATION: Liquid Level - Media: Liquid / Gas or Air (Density difference = 9x10-3 lbm/in3 to 72.2x10-3 lbm/in3) (Density difference = 250 kg/m³ to 2000 kg/m³) (Air 0.47x10-5 lbm/in3) DISPLACER MATERIAL: 1.4404 (316L) PRESSURE RATING: Up to PN 100 / Class 600 SUITABLE FOR FLANGE SIZE: (at Top of vessel/chamber 3 inch DISPLACER LENGTH "L": (inches are approx.) 300 mm (12 in) to 3000 mm (118 in) without partitioning MATERIAL & SUSPENSION LENGTH: (Length "b") 1.4404 (316L) / ... Customized length of Suspension {\par} OPTIONAL MODEL SUFFIX(ES) INCLUDED: Tag No. Labeling - Stainless Steel Label fixed with wire OPTIONAL MODEL SUFFIX(ES) INCLUDED: EN 10204-2.1 Certificate of Compliance OPTIONAL MODEL SUFFIX(ES) INCLUDED: EN 10204-3.1 Inspection Certificate Of Process Wetted Material Press Rating Chamber Class 300 Length "b" 3000 mm Length "L" 350 mm Upper Density 43.5 kg/m³ Static Pressure 55 bar Tag No. Labeling-L Blank Lower Density 1000 kg/m³ Used w/Transmitter 244LD |
| Weight | 15 |
Please contact us to request a price quote for Foxboro - 204DE-SSD6KS2-L13, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
