Fischer - PHASCOPE PMP10 DUPLEX / 603-689
| Manufacturer | Fischer |
|---|---|
| Part Number | PHASCOPE PMP10 DUPLEX / 603-689 |
| Inner Code | 4592066 |
| Technical specification | Particularly suitable for measuring duplex layers on steel or iron (e.g. lacquer/Zn/Fe) with simultaneous measurement of the individual thicknesses of paint and Zinc layer Also suitable for fire-galvanized layers without pronounced diffusion layer (< 1 μm) as well as for ZnAl alloy layers. It is necessary but calibration to the present metal layer material. Only in conjunction with ESG20 measuring probe General features: - Ergonomic design with large, backlit LC display - Alphanumeric data entry - Static evaluation with date and time - Menu-driven operator guidance - Automatic detection of base material and selection of measurement method - Memory for up to 100 applications divided into max. 4000 blocks - Dynamic storage space allocation for up to 20,000 measured values - RS 232 interface Selectable measurement modes: - Duplex measurement: measurement of duplex layers by combining magnetic inductive and phase sensitive eddy current method - ISO/NE (in duplex mode): measurement of electrically non-conductive Layers on non-ferrous metal substrates according to the eddy current method Automatic selection of duplex or ISO/NE measurement mode, depending on substrate material. - Dual mode: measurement of Ne/Fe or ISO/NE layers according to the magnetic inductive or eddy current method with automatic detection of base material. |
Please contact us to request a price quote for Fischer - PHASCOPE PMP10 DUPLEX / 603-689, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
