Filsa - DF21A1B1C5G2ER1AX1U5
| Manufacturer | Filsa |
|---|---|
| Part Number | DF21A1B1C5G2ER1AX1U5 |
| Inner Code | 4357513 |
| Description | Rotary leaf level gauge |
| Custom Code | 90318020 |
| Technical specification | molosRoto DF21 limit switch for bulk materials Full, empty and demand detectors for any installation position > >> wide range of applications << < A1 aluminum compact housing, protection class IP66, RAL 7001 Ambient temperature at control head Ta -20°C... 70°C B1 StaubEx II 1/2D Ex ta/tb IIIC T 80°C Da/Db for use in hazardous areas C5 operating voltage 24 V DC signal contact 1 mA 4 V... 2 A 240 V~, floating changeover contact gold-plated contacts (multi-voltage and multi-current switches) H0 function LEDs, yellow=on/blue=full/green=empty E0 bulk material temperature -25°C... 80°C P0 suitable for pressure in container -0.5 bar... 5 bar G2E process connection thread G1¼” from 1.4301 R1A oil seal made of PTFE/VITON with grease seal X1 measuring blade X50, 98x50 mm Length>LF< = 52mm U5 speed of measuring blade = 5 rpm |
Please contact us to request a price quote for Filsa - DF21A1B1C5G2ER1AX1U5, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
