Filsa - DF28A1C5F1ER1AS2LE 0500KD
| Manufacturer | Filsa |
|---|---|
| Part Number | DF28A1C5F1ER1AS2LE 0500KD |
| Inner Code | 4964167 |
| Custom Code | 90318020 |
| Technical specification | MolosRoto rotary vane level indicator DF28 limit switch for bulk materials Full, empty and demand detectors for vertical installation > >> with protective tube << < A1 aluminum compact housing, coated RAL 7001, IP66 Ambient temperature at the control head Ta -20°C... 70°C C5 operating voltage 24 V DC signal contact 1 mA 4 V... 2 A 240 V~, potential-free change-over gold-plated contacts (multi-voltage and multi-current switches) H0 Function LEDs, yellow=on/blue=full/green=empty E0 Bulk material temperature -25 °C... 80 °C P0 suitable for pressure in the container -0.5 bar... 5 bar F1E process connection flange F70 made of 1.4301 Dimensions Ø70, Ø110, LK90, 4xØ9 R1A PTFE/VITON shaft seal with grease seal S2 socket wing S, angled, 130x30 mm Length >LF< = 118 mm, measured on the shaft = 52 mm LE 0500 Protection tube length >LE< = 500 mm Cantilever length = 500 mm + >LF < KD storage with sealing ring at the end of the protective tube This means that any installation position is also possible |
Please contact us to request a price quote for Filsa - DF28A1C5F1ER1AS2LE 0500KD, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
