Filsa - DF21A1B1C5H9G2AS2
| Manufacturer | Filsa |
|---|---|
| Part Number | DF21A1B1C5H9G2AS2 |
| Inner Code | 4482373 |
| Description | Rotary wing level indicator |
| Custom Code | 90318020 |
| Technical specification | DF21 limit switch for bulk materials Full, empty and demand detectors for any installation position > >> large area of application << < A1 aluminium compact enclosure, RAL 7001, protection class IP66 Ambient temperature at the control head Ta -20°C... 70°C B1 StaubEx II 1/2D Exta/TB IIIC T80°C Da/Db for use in potentially explosive areas C5 operating voltage 24 V DC Signal contact 1 mA 4 V... 2 A 240 V~, floating changeover contact gold-plated contacts (multi-voltage and multi-current switches) H9 without functional LEDs E0 bulk material temperature -25 °C... 80 °C P0 suitable for pressure in the tank -0.5 bar... 5 bar G2A process connection thread G1¼” made of aluminum R0 standard shaft seal made of NBR, black S2 sleeve wings S, slanted, 130 x 30 mm length >LF< = 118 mm, measured on the shaft = 52 mm |
Please contact us to request a price quote for Filsa - DF21A1B1C5H9G2AS2, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
