Filsa - DF21A1B1C1F3CX6
| Manufacturer | Filsa |
|---|---|
| Part Number | DF21A1B1C1F3CX6 |
| Inner Code | 4968774 |
| Custom Code | 90318020 |
| Technical specification | MolosRoto rotary vane level indicator DF21 limit switch for bulk materials Full, empty and demand detectors for any installation position > >> wide range of applications << < A1 aluminum compact housing, coated RAL 7001, IP66 Ambient temperature at the control head Ta -20°C... 70°C B1 DustEx II 1/2D Ex ta/tb IIIC T80°C dA/dB for use in potentially explosive areas C1 operating voltage 220... 240 V AC (50... 60 Hz) signal contact 1 mA 4 V... 2 A 250 V~, potential-free change-over gold-plated contacts (multi-voltage and multi-current switches) H0 Function LEDs, yellow=on/blue=full/green=empty E0 Bulk material temperature -25 °C... 80 °C P0 suitable for pressure in the container -0.5 bar... 5 bar F3C process connection flange 200x25 galvanized steel Dimensions 200x2, Lk180, 6x8, IG R1¼ x 25 R0 standard NBR shaft seal, black X6 measuring blade X125, 125x50 mm (F) Length >LF< = 52 mm |
Please contact us to request a price quote for Filsa - DF21A1B1C1F3CX6, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
