Fife - 202570-001 / M289686
| Manufacturer | Fife |
|---|---|
| Part Number | 202570-001 / M289686 |
| Inner Code | 4617757 |
| Description | Fife D-MAX Network Operator Interface |
| Custom Code | 8537 10 98 |
| Technical specification | Fife D-MAX Network Operator Interface Model OI-N (network) high-resolution display 320x240pixels (QVGA) LED indicators for power supply and network connection membrane keyboard comprising: - 6 soft keys - arrow keys - Enter and Esc keys - Signal amplifier selection button network: 5-Port Ethernet Switch Hub with 100Mbs HMS Anybus CompactCom port for optional Anybus module, available for the following field buses: Profibus, devicenet Power supply 24-48Vdc (21-51Vdc min-max) Max. current consumption 0.8A Max power 20W Protection class IP-54 (installation in the control panel) IP-30 (wall mounting) Operating temperature 0° to 60° C Dimensions 88x145x194mm |
Please contact us to request a price quote for Fife - 202570-001 / M289686, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
