Erhardt Leimer - 00540030
| Manufacturer | Erhardt Leimer |
|---|---|
| Part Number | 00540030 |
| Inner Code | 4700048 |
| Description | swivel frame system |
| Technical specification | DRS12 with compact DR 1275 swivel frame, to regulate a running track, with digital position controller and electric actuator. Country of Origin: Germany (DE) HS 84798997 With the following configuration: E+L system: DRS1202 DR - Series: DR 1275 Nominal width NB: 250 mm LUE transfer length: 180 mm Guiding system: track edge control Sensor: FX 46 ultrasonic sensor Sensor rod: standard version Operating voltage: 24V DC 2.5A roller diameter: 40 mm Inlet roller surface: hard-anodized aluminum RA=6.3μm Spout roller surface: hard-anodized aluminum RA=6.3μm Data format: CAN 1.0 - Control panel: RT 4006 standard Control panel: I/O interface LK 4002 Installation arrangement: 2-E2-A1-A-LR Factory standard:555711 Assembly: with groove blocks Tread cleaning: Yes Correction path max.: 38 mm Rail train max.: 300 N Colour: RAL 7021 black grey Dimension sheet: DRS12__-157870M Com.No. 374265 |
Please contact us to request a price quote for Erhardt Leimer - 00540030, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
