Elomatic - FS 200-E- 82NM-F10-SW22
| Manufacturer | Elomatic |
|---|---|
| Part Number | FS 200-E- 82NM-F10-SW22 |
| Inner Code | 4183440 |
| Description | QUARTER-TURN DRIVE |
| Technical specification | Quarter turn actuator single acting Manufacture/Type: ELOMATIC FS200 With connection flange to DIN-ISO 5211-F10 and internal square according to DIN 3337, SW22 Interface Connections to NAMUR and VDI/VDE 3845, Minimum torque at 0 degrees and 4 bar Control pressure: 82 Nm Minimum torque of the spring packages at 90 degrees: 82 Nm, spring set no. 40 Type Code: FS0200 M40CWALS YD22 SKA00XX |
Please contact us to request a price quote for Elomatic - FS 200-E- 82NM-F10-SW22, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
