Eisele - V86135, GTWSI-EX 204
| Manufacturer | Eisele |
|---|---|
| Part Number | V86135, GTWSI-EX 204 |
| Inner Code | 4462099 |
| Description | mixer |
| Technical specification | Eisele - submersible agitator built according to Directive 94/9/EC equipment group II category IIG for zone 1 Model GTWS: GTWSI-EX 204 Propellers: V84106 propeller GTW 204 V2A Rubber cable: M84663 rubber cable complete 7x4+4x1 14 meters without motor protection switch Sledge: 1 with sled Sliding profile: V85853 sliding profile 100 cpl. Bolt: V85875 pin profile 100 cpl. *Biogas execution* - three-phase motor - 15.0 kW/20.0 hp, 400 V, 50 Hz, 240 rpm - Ignition protection class e, temperature class T3 - ATEX certificate (II 2G Ex e T3 0°C <=Ta<=65°C) - Sealing probe - for explosion protection zones 1 and 2 - Insulation class H (180°C); protection class IP68 - max. ambient temperature +65°C - additional labyrinth ring on the propeller - PTC conductor instead of thermal contact |
Please contact us to request a price quote for Eisele - V86135, GTWSI-EX 204, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
