Dynisco - PT462E
| Manufacturer | Dynisco |
|---|---|
| Part Number | PT462E |
| Inner Code | 387826 |
| Description | pressure sensor |
| Technical specification | Ranges (psi): 0 - 500, 0 - 750, 0 - 1,000, 0 - 1,500, 0 - 3,000, 0 - 5,000, 0 - 7,500, 0 - 10,000, 0 - 15,000, 0 - 20,000, 0 - 30,000. Accuracy: ±0.5% FSO. Repeatability: ±0.2% FSO. Mounting torque: 500 inch - lbs. maximum. Maximum pressure: 2 x full range or 35,000 psi . Material in contact with pressure media: 15 - 5 PH stainless steel. Weight: 0.68 kg. Bridge resistance: Input: 345 Ohms minimum; Output: 350 Ohms ±10 Full scale output: 3.33 mV/V ±2%. Zero balance: ±10% full scale. Excitation: 10 Vdc recommended, 12 Vdc maximum. Internal shunt calibration (R-Cal): 80% FSO ±1.0%. Insulation resistance: 1,000 megohms at 50 Vdc. |
| Weight | 1 |
Please contact us to request a price quote for Dynisco - PT462E, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
