Dwyer - V10SS
| Manufacturer | Dwyer |
|---|---|
| Part Number | V10SS |
| Inner Code | 471842 |
| Description | Mini-Size Flow Switch |
| Technical specification | Wetted Materials Vane: 301 SS Body: Brass or 303 SS Pin and Spring: 301 SS, 302 SS and 316 SS Magnet: Ceramic 8 Temperature Limit 200°F (93°C) Pressure Limit Brass body: 1000 psig (69 bar) 303 SS body: 2000 psig (138 bar) Enclosure Rating Weatherproof, meets NEMA 4X (IP66) Switch Type SPST hermetically sealed reed switch. Field adjustable for normally open or normally closed Electrical Rating 0.5 A at 120 VAC 1.5 A at 24 VDC res 0.001 A at 200 VDC res Electrical Connections 18 AWG, 19" (483 mm) long, PVC jacket. Rated 221°F (105°C) Process Connection 1/2˝ male NPT standard. Contact factory for other options |
| Weight | 1 |
Please contact us to request a price quote for Dwyer - V10SS, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
