Dwyer - MS-111-LCD
| Manufacturer | Dwyer |
|---|---|
| Part Number | MS-111-LCD |
| Inner Code | 351493 |
| Description | Pressure Transmitter |
| Technical specification | General Specifications Power Requirements: 10 to 35 VDC (2-wire) 17 to 36 VDC or isolated 21.6 to 33 VAC (3-wire) Service: Air and non-combustible compatible gases Stability: ±1% F.S./year Temperature Limits: 0 to 150°F (-18 to 66°C) Pressure Limits: 1 psi maximum, operation; 10 psi, burst Output Signals: 4 to 20 mA (2-wire); 0 to 5 V, 0 to 10 V (3-wire) Response Time: Field adjustable 0.5 to 15 sec. time constant. Provides a 95% response time of 1.5 to 45 seconds Zero & Span Adjustments: Digital push button Loop Resistance: Current Output: 0-1250 max. Voltage Output: min. load resistance 1 k Current Consumption: 40 mA max Display (optional): 4 digit LCD Electrical Entry: 1/2" NPS Thread. Accessory: Cable Gland for 5 to 10 mm diameter cable Process Connection: 3/16" (5 mm) ID tubing. Maximum OD 9 mm Enclosure Rating: NEMA 4X (IP66) Mounting Orientation: Diaphragm in vertical position |
| Weight | 1 |
Please contact us to request a price quote for Dwyer - MS-111-LCD, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
